Dynamic configuration API

This document describes the API endpoints to retrieve and manage the dynamic configurations for the Coordinator and Overlord in Apache Druid.

In this document, http://SERVICE_IP:SERVICE_PORT is a placeholder for the server address of deployment and the service port. For example, on the quickstart configuration, replace http://ROUTER_IP:ROUTER_PORT with http://localhost:8888.

Coordinator dynamic configuration

The Coordinator has dynamic configurations to tune certain behavior on the fly, without requiring a service restart. For more information, see Coordinator Dynamic Configuration.

Update Coordinator dynamic configuration

Update Coordinator dynamic worker configuration. Pass the dynamic configuration spec as a JSON request body. For information on constructing a dynamic configuration spec, see Dynamic configuration.

URL

POST /druid/coordinator/v1/config

Responses

Successfully updated dynamic configuration

Sample request

curl "http://ROUTER_IP:ROUTER_PORT/druid/coordinator/v1/config" \
--header 'Content-Type: application/json' \
--data '{
  "millisToWaitBeforeDeleting": 900000,
  "mergeBytesLimit": 524288000,
  "mergeSegmentsLimit": 100,
  "maxSegmentsToMove": 5,
  "percentOfSegmentsToConsiderPerMove": 100,
  "useBatchedSegmentSampler": true,
  "replicantLifetime": 15,
  "replicationThrottleLimit": 10,
  "balancerComputeThreads": 1,
  "emitBalancingStats": true,
  "killDataSourceWhitelist": [],
  "killPendingSegmentsSkipList": [],
  "maxSegmentsInNodeLoadingQueue": 100,
  "decommissioningNodes": [],
  "decommissioningMaxPercentOfMaxSegmentsToMove": 70,
  "pauseCoordination": false,
  "replicateAfterLoadTimeout": false,
  "maxNonPrimaryReplicantsToLoad": 2147483647,
  "useRoundRobinSegmentAssignment": true
}'
POST /druid/coordinator/v1/config HTTP/1.1
Host: http://ROUTER_IP:ROUTER_PORT
Content-Type: application/json
Content-Length: 683

{
  "millisToWaitBeforeDeleting": 900000,
  "mergeBytesLimit": 524288000,
  "mergeSegmentsLimit": 100,
  "maxSegmentsToMove": 5,
  "percentOfSegmentsToConsiderPerMove": 100,
  "useBatchedSegmentSampler": true,
  "replicantLifetime": 15,
  "replicationThrottleLimit": 10,
  "balancerComputeThreads": 1,
  "emitBalancingStats": true,
  "killDataSourceWhitelist": [],
  "killPendingSegmentsSkipList": [],
  "maxSegmentsInNodeLoadingQueue": 100,
  "decommissioningNodes": [],
  "decommissioningMaxPercentOfMaxSegmentsToMove": 70,
  "pauseCoordination": false,
  "replicateAfterLoadTimeout": false,
  "maxNonPrimaryReplicantsToLoad": 2147483647,
  "useRoundRobinSegmentAssignment": true
}

Sample response

A successful request returns an HTTP 200 OK message code and an empty response body.

Get Coordinator dynamic configuration

Retrieves current Coordinator dynamic configuration. Returns a JSON object with the dynamic configuration properties and values. For information on the response properties, see Dynamic configuration.

URL

GET /druid/coordinator/v1/config

Responses

Successfully retrieved dynamic configuration

Sample request

curl "http://ROUTER_IP:ROUTER_PORT/druid/coordinator/v1/config"
GET /druid/coordinator/v1/config HTTP/1.1
Host: http://ROUTER_IP:ROUTER_PORT

Sample response

Click to show sample response

{
    "millisToWaitBeforeDeleting": 900000,
    "mergeBytesLimit": 524288000,
    "mergeSegmentsLimit": 100,
    "maxSegmentsToMove": 5,
    "percentOfSegmentsToConsiderPerMove": 100.0,
    "useBatchedSegmentSampler": true,
    "replicantLifetime": 15,
    "replicationThrottleLimit": 10,
    "balancerComputeThreads": 1,
    "emitBalancingStats": false,
    "killDataSourceWhitelist": [],
    "killPendingSegmentsSkipList": [],
    "maxSegmentsInNodeLoadingQueue": 100,
    "decommissioningNodes": [],
    "decommissioningMaxPercentOfMaxSegmentsToMove": 70,
    "pauseCoordination": false,
    "replicateAfterLoadTimeout": false,
    "maxNonPrimaryReplicantsToLoad": 2147483647,
    "useRoundRobinSegmentAssignment": true
}

Get Coordinator dynamic configuration history

Retrieves the history of changes to Coordinator dynamic configuration over an interval of time. Returns an empty array if there are no history records available.

URL

GET /druid/coordinator/v1/config/history

Query parameters

  • interval (optional)

    • Type: ISO 8601
    • Limits the number of results to the specified time interval. Delimited with /. For example, 2023-07-13/2023-07-19.

  • count (optional)

    • Type: Int
    • Limits the number of results to the last n entries.

Responses

Successfully retrieved history

Sample request

The following example retrieves the dynamic configuration history between 2022-07-13 and 2024-07-19. The response is limited to 10 entries.

curl "http://ROUTER_IP:ROUTER_PORT/druid/coordinator/v1/config/history?interval=2022-07-13%2F2024-07-19&count=10"
GET /druid/coordinator/v1/config/history?interval=2022-07-13/2024-07-19&count=10 HTTP/1.1
Host: http://ROUTER_IP:ROUTER_PORT

Sample response

Click to show sample response

[
    {
        "key": "coordinator.config",
        "type": "coordinator.config",
        "auditInfo": {
            "author": "console",
            "comment": "testing config change",
            "ip": "127.0.0.1"
        },
        "payload": "{\"millisToWaitBeforeDeleting\":900000,\"mergeBytesLimit\":524288000,\"mergeSegmentsLimit\":100,\"maxSegmentsToMove\":5,\"percentOfSegmentsToConsiderPerMove\":100.0,\"useBatchedSegmentSampler\":true,\"replicantLifetime\":15,\"replicationThrottleLimit\":10,\"balancerComputeThreads\":1,\"emitBalancingStats\":false,\"killDataSourceWhitelist\":[],\"killPendingSegmentsSkipList\":[],\"maxSegmentsInNodeLoadingQueue\":100,\"decommissioningNodes\":[],\"decommissioningMaxPercentOfMaxSegmentsToMove\":70,\"pauseCoordination\":false,\"replicateAfterLoadTimeout\":false,\"maxNonPrimaryReplicantsToLoad\":2147483647,\"useRoundRobinSegmentAssignment\":true}",
        "auditTime": "2023-08-12T07:51:36.306Z"
    }
]

Overlord dynamic configuration

The Overlord can be dynamically configured to specify how tasks are assigned to workers. For more information, see Overlord dynamic configuration.

Update Overlord dynamic configuration.

Updates overlord dynamic worker configuration. Pass the dynamic configuration spec as a JSON request body. For information on constructing an Overlord dynamic configuration spec, see Overlord dynamic configuration.

URL

POST/druid/indexer/v1/worker

Header parameters

The endpoint supports a set of optional header parameters to populate the author and comment fields in the configuration history.

  • X-Druid-Author (optional)
    • Type: String
    • A string representing the author making the configuration change.
  • X-Druid-Comment (optional)
    • Type: String
    • A string describing the update.

Responses

Successfully updated dynamic configuration

Sample request

curl "http://ROUTER_IP:ROUTER_PORT/druid/indexer/v1/worker" \
--header 'Content-Type: application/json' \
--data '{
  "type": "default",
  "selectStrategy": {
    "type": "fillCapacityWithCategorySpec",
    "workerCategorySpec": {
      "categoryMap": {},
      "strong": true
    }
  },
  "autoScaler": null
}'
POST /druid/indexer/v1/worker HTTP/1.1
Host: http://ROUTER_IP:ROUTER_PORT
Content-Type: application/json
Content-Length: 196

{
  "type": "default",
  "selectStrategy": {
    "type": "fillCapacityWithCategorySpec",
    "workerCategorySpec": {
      "categoryMap": {},
      "strong": true
    }
  },
  "autoScaler": null
}

Sample response

A successful request returns an HTTP 200 OK message code and an empty response body.

Get Overlord dynamic configuration

Returns current Overlord dynamic configuration. Returns an empty response body if there are no current Overlord dynamic configuration.

URL

GET /druid/indexer/v1/worker

Responses

Successfully retrieved dynamic configuration

Sample request

curl "http://ROUTER_IP:ROUTER_PORT/druid/indexer/v1/worker"
GET /druid/indexer/v1/worker HTTP/1.1
Host: http://ROUTER_IP:ROUTER_PORT

Sample response

Click to show sample response

{
    "type": "default",
    "selectStrategy": {
        "type": "fillCapacityWithCategorySpec",
        "workerCategorySpec": {
            "categoryMap": {},
            "strong": true
        }
    },
    "autoScaler": null
}

Get Overlord dynamic configuration history

Retrieves history of changes to Overlord dynamic configuration. Returns an empty array if there are no history records available.

URL

GET /druid/indexer/v1/worker/history

Query parameters

  • interval (optional)

    • Type: ISO 8601
    • Limits the number of results to the specified time interval. Delimited with /. For example, 2023-07-13/2023-07-19.

  • count (optional)

    • Type: Int
    • Limits the number of results to the last n entries.

Responses

Successfully retrieved history

Sample request

The following example retrieves the dynamic configuration history between 2022-07-13 and 2024-07-19. The response is limited to 10 entries.

curl "http://ROUTER_IP:ROUTER_PORT/druid/indexer/v1/worker/history?interval=2022-07-13%2F2024-07-19&count=10"
GET /druid/indexer/v1/worker/history?interval=2022-07-13%2F2024-07-19&count=10 HTTP/1.1
Host: http://ROUTER_IP:ROUTER_PORT

Sample response

Click to show sample response

[
    {
        "key": "worker.config",
        "type": "worker.config",
        "auditInfo": {
            "author": "",
            "comment": "",
            "ip": "127.0.0.1"
        },
        "payload": "{\"type\":\"default\",\"selectStrategy\":{\"type\":\"fillCapacityWithCategorySpec\",\"workerCategorySpec\":{\"categoryMap\":{},\"strong\":true}},\"autoScaler\":null}",
        "auditTime": "2023-08-15T20:32:06.899Z"
    }
]

Get an array of worker nodes in the cluster

Returns an array of all the worker nodes in the cluster along with its corresponding metadata.

GET/druid/indexer/v1/workers

Responses

Successfully retrieved worker nodes

Sample request

curl "http://ROUTER_IP:ROUTER_PORT/druid/indexer/v1/workers"
GET /druid/indexer/v1/workers HTTP/1.1
Host: http://ROUTER_IP:ROUTER_PORT

Sample response

Click to show sample response

[
    {
        "worker": {
            "scheme": "http",
            "host": "localhost:8091",
            "ip": "192.168.1.4",
            "capacity": 2,
            "version": "0",
            "category": "_default_worker_category"
        },
        "currCapacityUsed": 0,
        "currParallelIndexCapacityUsed": 0,
        "availabilityGroups": [],
        "runningTasks": [],
        "lastCompletedTaskTime": "2023-08-15T18:19:37.254Z",
        "blacklistedUntil": null
    }
]

Get scaling events

Returns Overlord scaling events if auto-scaling runners are in use.

URL

GET/druid/indexer/v1/scaling

Responses

Successfully retrieved scaling events

Sample request

curl "http://ROUTER_IP:ROUTER_PORT/druid/indexer/v1/scaling"
GET /druid/indexer/v1/scaling HTTP/1.1
Host: http://ROUTER_IP:ROUTER_PORT

Sample response

Click to show sample response
